WLC-3250
- Access points number:
- 3000
- Interfaces:
- 8x1G Combo SFP, 4x25G
- Power supply:
- AC/DC, 2 hot-swappable power modules
Description
WLC-3250 are enterprise-level controllers for small- and medium-sized enterprises. The devices allow building distributed wireless networks using different traffic scenarios at L2/L3 level. Firewall features are supported on WLC controllers to ensure network security. The devices can be used to create various user authorization scenarios for corporate and guest networks. LDAP, RADIUS and other corporate services are also available.
Built-in AirTune module allows managing radio parameters of access points (AP) and client balancing, as well as adapting to the current environment. Seamless roaming support (802.11r/k/v) provides the best conditions for client switching between AP.
Advanced warranty and support packages
Extend basic package with additional paid services
Learn more
Specifications
- Access points number:
- 3000
- Maximum clients number:
- 70000
- Interfaces:
- 8x1G Combo SFP, 4x25G
- Access points monitoring
- User authorization:
- WPA/WPA2/WPA3 (Personal/Enterprise)
- Security:
- Firewall/IPS/IDS
- Expansion of access points number is available under license:
- up to 5000
Features and capabilities
For full specifications and manuals see Documents and files section below
Interfaces:
Combo 10/100/1000BASE-T/1000BASE-X (SFP)
8
1000BASE-X/10GBASE-R/25GBASE-R (LAN/WAN)
4
Console (RJ-45)
1
USB 3.0
2
HDD slot
1
microSD card slot
1
System features:
Access points number
3000 (expansion of access points number is available under license - up to 5000 APs)
Maximum clients number
70000
VPN tunnels
500
Static routes
11К
Concurrent sessions
8,5M
VLAN support
Up to 4094 active VLANs according to 802.1Q
BGP routes
5М
OSPF routes
500К
RIP routes
10k
MAC table
16К entries per bridge
FIB size
1,7М
VRF
32
Physical specifications:
RAM
32 GB DDR4
Flash memory
256 GB eMMC
Maximum power consumption
74 W
Power supply
100–240 V АС, 50–60 Hz
36–72 V DC
Up to 2 hot-swappable power modules
Operating temperature
From -10 to +45 °C
Storage temperature
From -40 to +70 °C
Operating humidity
No more than 80 %
Storage humidity
From 10 to 95 %
Dimensions (WxHxD)
430x43,6x329 mm
Weight
4,232 kg
Access points management:
WPA/WPA2/WPA3
Personal
Yes (WPA3 and OWE are supported for WEP-3ax, WEP-3L, WEP-30L, WEP-30L-Z, WEP-550K, WOP-30L, WOP-30LI, WOP-30LS APs)
WPA/WPA2/WPA3 Enterprise
Yes (WPA3 and OWE are supported for WEP-3ax, WEP-3L, WEP-30L, WEP-30L-Z, WEP-550K, WOP-30L, WOP-30LI, WOP-30LS APs)
OWE open network
Yes (WPA3 and OWE are supported for WEP-3ax, WEP-3L, WEP-30L, WEP-30L-Z, WEP-550K, WOP-30L, WOP-30LI, WOP-30LS APs)
Collecting user account information to an external RADIUS server
Yes
IEEE 802.11r/k/v standard seamless roaming
Yes
Integration with external portals
Yes (Operation with ELTEX-NAICE, WNAM Netams, Cisco ISE is tested)
Automatic management of radio environment resources
Yes
Access point authorization by certificate
Yes
Supported access points:
WEP-1L
WEP-2L
WEP-3L
WEP-200L
WEP-30L
WEP-30L-Z
WEP-3ax
WEP-550K
WOP-2L
WOP-20L
WOP-30L
WOP-30LI
WOP-30LS
WOP-30L-EX
WEP-2ac
WEP-2ac Smart
WOP-2ac
WOP-2ac rev.B
WOP-2ac rev.C
