Service Gateways
ESR is a high-performance network security solution for enterprises and service providers that high port density, advanced security and flexible connectivity into one easily managed platform.
New
ESR virtual service router providing firewall and router functions.
ESR-10 service router, 4×Ethernet 10/100/1000BASE-T, 2×1000BASE-X (SFP), 1×Console RS-232 (RJ-45), 2×USB 2.0, 1 GB RAM, 512 MB NAND-Flash, 12 V DC, 230 V AC
(via 12 V, 1.5 A power adapter).
Available for personal order
ESR-12V service router, 8×Ethernet 10/100/1000BASE-T, 1×Console RS-232
(RJ-45), 2×USB 2.0, 3×FXS, 1×FXO, 1 GB RAM, 512 MB NAND-Flash, 100–264 V AC.
ESR-12VF service router, 8×Ethernet 10/100/1000BASE-T, 1×1000BASE-X (SFP), 1×Console RS-232 (RJ-45), 2×USB 2.0, 3×FXS, 1×FXO,1 GB RAM, 512 MB NAND-Flash, 100–264 V AC
New
ESR-15 service router, 4×Ethernet 10/100/1000BASE-T, 2×1000BASE-X SFP, 1×Console RS-232 (RJ-45), 2×USB 2.0, 4 GB RAM, 230 V AC (via 12 V, 2 А power
adapter).
New
2x1000BASE-X SFP
8x10/100/1000BASE-T
8x10/100/1000BASE-T
New
2x1000BASE-X SFP
4x10/100/1000BASE-T
4x10/100/1000BASE-T
ESR-20 service router, 2×10/100/1000BASE-T, 2×Combo 10/100/1000BASE-T/1000BASE-X (SFP), 1×Console RS-232 (RJ-45), 1×USB 2.0, 1×USB 3.0, 1 slot for SD cards, 4 GB RAM, 4 GB Flash, 100–264 V AC.
ESR-21 service router, 8х10/100/1000BASE-T, 2x10/100/1000BASE-X, 1xUSB 2.0, 1xUSB 3.0, 1 slot for SD cards, Console, Serial (RS-232), 4GB RAM, 4GB Flash, 220V AC built-in power module
Bestseller
ESR-30 service router, 4×10/100/1000BASE-T, 2×10GBASE-R/1000BASE-X (SFP+/SFP), 1×Console RS-232 (RJ-45), 1×USB 2.0, 1×USB 3.0, 1 slot for microSD cards, 4 GB RAM, 100–264 V AC.
New
8x10/100/1000BASE-T;
6x1000BASE-X SFP;
2x10GBASE-R SFP+/1000BASE-X SFP;
3xSerial (RS-232)
6x1000BASE-X SFP;
2x10GBASE-R SFP+/1000BASE-X SFP;
3xSerial (RS-232)
Production is over
Service Gateway ESR-100: 4хCombo 10/100/1000BASE-T/1000BASE-X SFP, 1xUSB2.0, 1xUSB3.0, 1 slot for SD-card, 4Gb RAM, 1 Gb Flash, 220V AC
Service Gateway ESR-200: 4х10/100/1000BASE-T, 4xCombo 10/100/1000BASE-T1000BASE-X SFP, NAT, Firewall, L3 routing
Production is over
IPSec VPN, Firewall protection and NAT, L3 Routing, 5,9 Gbps
Available for personal order
IPSec VPN, Firewall protection and NAT, L3 Routing, 5,9 Gbps
Available for personal order
4 ports of Combo 10/100/1000Base-T/ 1000Base-X
4 ports of Ethernet 10/100/1000Base-T
4 ports of 10GBase-R SFP+/1000Base-X
4 ports of Ethernet 10/100/1000Base-T
4 ports of 10GBase-R SFP+/1000Base-X
4хCombo 10/100/1000BASE-T/1000BASE-X
8х10GBASE-R SFP+
32GB RAM, 1GB SSD
2 slots for 220V AC or 48V DC power modules
8х10GBASE-R SFP+
32GB RAM, 1GB SSD
2 slots for 220V AC or 48V DC power modules
4 ports of Combo 10/100/1000Base-T/ 1000Base-X
4 ports of Ethernet 10/100/1000Base-T
4 ports of 10GBase-R SFP+/1000Base-X
2 ports of 40GBASE-X QSFP+ (LAN/WAN)
4 ports of Ethernet 10/100/1000Base-T
4 ports of 10GBase-R SFP+/1000Base-X
2 ports of 40GBASE-X QSFP+ (LAN/WAN)
12x1000BASE-X/10GBASE-R/25GBASE-R (LAN/WAN)
New
12x1000BASE-X/10GBASE-R/25GBASE-R (LAN/WAN)
New
4x1000BASE-X/10GBASE-R/25GBASE-R;
8x10GBASE-R SFP+/1000BASE-X SFP (LAN/WAN);
1xOOB
8x10GBASE-R SFP+/1000BASE-X SFP (LAN/WAN);
1xOOB
New
4x1000BASE-X/10GBASE-R/25GBASE-R;
4x40GBASE-R QSFP+/100GBASE-R QSFP28;
1xOOB
4x40GBASE-R QSFP+/100GBASE-R QSFP28;
1xOOB
