ESR-15R-4G
- Interfaces:
- 4x1G, 2x1G SFP
- Power supply:
- DC
Description
ESR-15R-4G is a service routers designed for connection of small and middle-sized offices in enterprise networks. The firewall and router functions ensure security with various Internet connection options. The device supports advanced routing, WAN organization and network security functions.
ESR-15R-4G has build-in 4G (LTE) modem with SIM cards support, which ensures main or backup access channel for data transmission.
Advanced warranty and support packages
Extend basic package with additional paid services
Learn more
Specifications
Features and capabilities
For full specifications and manuals see Documents and files section below
Interfaces:
Ethernet 10/100/1000BASE-T (RJ-45)
4
Ethernet 1000BASE-X (SFP)
2
Console RS-232 (RJ-45)
1
USB 2.0
1
nanoSIM card slot
2
SMA-F port for antenna connection
4
Network and service functions:
Switching
Sub
QinQ
Bridge
Routing
BGP
OSPFv3
OSPFv3
RIP
Tunneling
IPIP
GRE
Ethernet over GRE
GRE SUB
SoftGRE
L2TPv3
LT
IPsec VTI
Remote Access
L2TP tunnels (client)
PPTP tunnels (client)
OpenVPN tunnels (client)
OpenVPN remote addresses per tunnel
Security
ACL
Zone-based Firewall
Protection against DoS/DDoS/Spoof attacks and their logging
IPS/IDS
Filtering by applications
Backup and clustering
VRRP v2, v3
Tracking
DHCP failover for IP addresses base backup issued by the DCHP server
Firewall failover for Firewall and NAT session backup
MultiWAN
Dual-Homing
Management and monitoring
Support for standard and extended SNMP MIB,
RMONv1
Zabbix agent/proxy
User authentication using local database via RADIUS, TACACS+, LDAP
Protection against configuration errors, automatic configuration recovery
CLI
Syslog
System resource usage monitoring
Ping, monitor, traceroute (IPv4/IPv6), output packet information in console
Firmware upgrade, configuration upload and download via TFTP, SCP, FTP, SFTP, HTTP(S)
Support for NTP
Netflow v5/v9/v10 (exporting of URL statistics for HTTP, host for HTTPS)
Local management via RS-232 (RJ-45) console port
Remote management, Telnet, SSH (IPv4/IPv6)
LLDP, LLDP MED
Local and remote saving of router configurations
Physical specifications and environmental parameters:
RAM
4 GB DDR4
Flash
8 GB eMMC
Power supply
24–48 V DC
Operating temperature
From 0 to +40 °С
Storage temperature
From -40 to +70 °С
Operating humidity
No more than 80 %
Storage humidity
From 10 to 95 %
Dimensions (WxHxD)
175.5x43.6x153.5 mm
Weight
1.137 kg
