ST-SBR two-gang wireless switch

Two-gang wireless switch that operates under Matter over Thread technology
ΠΏΡ€ΠΎΠ΄ΡƒΠΊΡ‚
ΠΏΡ€ΠΎΠ΄ΡƒΠΊΡ‚
ΠΏΡ€ΠΎΠ΄ΡƒΠΊΡ‚
ΠΏΡ€ΠΎΠ΄ΡƒΠΊΡ‚
ΠΏΡ€ΠΎΠ΄ΡƒΠΊΡ‚
ΠΏΡ€ΠΎΠ΄ΡƒΠΊΡ‚
ΠΏΡ€ΠΎΠ΄ΡƒΠΊΡ‚
Under development

Description

ST-SBR is a two-gang wireless switch that operates under Matter over Thread technology. The device is battery-powered and can be installed in any location without wires.


Eltex smart home

ST-MCT is part of the Eltex smart home ecosystem based on the ELIS (Eltex Smart IoT System) platform. Users manage smart devices and sensors via a smart home hub using an iOS or Android mobile device with the Eltex Home app installed. It can be downloaded from the App Store and Google Play. The app is also available in Huawei AppGallery.


ST-SBR makes it possible to control other smart home devices, such as Wi-Fi relays and sockets, as well as run customized scenarios. An Eltex hub with Matter over Thread technology support is required to connect the sensor to the network, specifically the SH-130 model.

Advanced warranty and support packages
Extend basic package with additional paid services
Learn more

Specifications

Control of lighting and other devices
Operation in smart home scenarios
Support for Matter over Thread protocol
Features and capabilities
For full specifications and manuals see Documents and files section below
Data sheet
General features:
Power
1xCR2450 battery
Signal frequency
2.4 GHz
Maximum distance from the hub
120 m (within line of sight)
Ingress protection
IΠ 20
Dimensions (WxHxD)
85x85x5 mm
Weight including batteries
0,08 kg
Operating humidity at +40 Β°C
Up to 93 % without condensation
Operating temperature
From +5 to +45 Β°C
Maximum RF strength
+14 dBm
