SH-130 smart home hub

Eltex Home hub that enables control of household appliances via built-in IR remote
продукт
продукт
продукт
продукт
Under development

Description

SH-130 is an Eltex Home hub that enables control of household appliances via built-in IR remote. The device is designed to provide a unified system for managing, configuring, and monitoring Eltex smart devices. The hub supports Wi-Fi, Z-Wave, Zigbee, Matter over Wi-Fi, Matter over Thread protocols.


Device management

To monitor and control a smart home device network, connect the SH-130 hub to your Wi-Fi router via wired or wireless connection.

Any mobile device running iOS or Android with the Eltex Home app installed can serve as the universal control re mote for the SH-130. The app can be downloaded from the App Store and Google Play or via the QR code below. The app is also available in RuStore and Huawei AppGallery.


Eltex Home features

Using the SH-130 hub together with the Eltex Home app allows:

  1. Receiving event notifications to a mobile device.
  2. Working with the following services:
    1. "Security" — to keep the premises safe (detection of unauthorized access).
    2. "Control" — to ensure a comfortable environment (monitoring temperature and humidity levels, detecting emergencies as smoke or water leaks).
    3. "Management" — to control the operation of lighting and household appliances (automatic switching lights on when entering a room, flexible setting of lighting channels, switching appliances on and off, etc.).
  3. Creating scenarios for smart devices to work together. For maximum convenience, it is possible to set devices in  the home to work in the desired mode, specifying conditions, sequence and time of required actions
Advanced warranty and support packages
Extend basic package with additional paid services
Learn more

Specifications

Built-in IR remote
Wi-Fi IEEE:
802.11a/b/g/n/ac
100 Mbps Ethernet port
Support:
Wi-Fi, Z-Wave, Zigbee, Matter over Wi-Fi, Matter over Thread
Features and capabilities
For full specifications and manuals see Documents and files section below
Data sheet
Hardware features:
RAM
1 GB
Interfaces:
LAN 10/100/BASE-T (RJ-45)
1
USB 2.0
2
Wi-Fi
IEEE 802.11b/g/n, 2.4 GHz
IEEE 802.11a/n/ac, 5 GHz
Z-Wave
869 MHz
Zigbee
IEEE 802.15.4, 2.4 GHz
Thread
2.4 GHz
Bluetooth 5.4
2.4 GHz
Built-in IR remote
Yes
Wireless interface parameters:
Number of antennas
2
Type of antennas
Built-in
Support for Wi-Fi IEEE 802.11b/g/n
Yes
Frequency range
2400–2483.5 MHz
MIMO
2x2 (2.4 GHz)
Modulation
SSS, CCK, BPSK, QPSK, 16QAM, 64QAM
Z-Wave module parameters:
Number of antennas
1
Type of antennas
Built-in
Frequency range
869 MHz
Maximum power of the transmitter
14 dBm
Receiver sensitivity
Up to -104 dBm
Physical parameters:
Power adapter
12 V, 2 A
Peak power
17 W
USB port load capacity
1x0,6 А
1x1,2 А
IR remote operating range
Up to 12 m (transmission)
Operating temperature
From 0 to +40 °С
Dimensions (WxHxD)
128x119x28 mm
Weight
153,5 g
