Power module PM65-220/12
- Type:
- AC/DC
- Output voltage:
- 12 V
- Max. output power:
- 65 W
Description
PM65-220/12 power modules are intended to be used for the following Eltex equipment: aggregation switches, industrial switches, service gateways.
Specifications
For full specifications and manuals see Documents and files section below
Electrical features:
Input voltage АС max. range
90–264 V AC
Input voltage АС nominal
range
100–240 V AC
Input voltage DС max. range
120–370 V DC
Input frequency
47–63 Hz
Output voltage
12 V
Max. output power:
65 W
Inrush current
30 А
Physical features and ambient parameters:
Operating temperature
From -40 to +70 °С
Storage temperature
From -50 to +75 °С
Operating humidity at +25 °C
(without condensation)
Up to 80 %
Dimensions (WxHxD)
86х44х156 mm
Weigh
0.47 kg
Supported devices
Aggregation Switch MES3300-08F
Aggregation Switch MES3300-16F
Aggregation Switch MES3300-24
Aggregation Switch MES3300-24F
Aggregation Switch MES3300-48
Ethernet Aggregation Switch MES3308F
