Power module PM300T-48/12

Description

PM300T-48/12 power modules are intended to be used for the following Eltex equipment: ME2001.

For full specifications and manuals see Documents and files section below

Electrical features:

Input voltage DС max. rang

36–72 V

Inrush current

40 А (Vin=48 V)

40 А (Vin=72 V)

Output voltage

12 V

Max. output power

300 W

Physical features and ambient parameters:

Operating temperature

From 0 to +55 °C

Storage temperature

From -40 to +70 °C

Operating humidity at +25 °C (without condensation)

Up to 95 %

Dimensions (WxHxD)

54x40x249 mm

Weigh

0.55 kg
