Power module PM300T-220/12
- Type:
- AC
- Output voltage:
- 12 V
- Max. output power:
- 300 W
Description
PM300T-220/12 power modules are intended to be used for the following Eltex equipment: ME2001.
Specifications
For full specifications and manuals see Documents and files section below
Electrical features:
Input voltage АС max. range
90–264 V
Input voltage АС nominal range
100–240 V
Input frequency
47–63 Hz
Inrush current
30 А
Output voltage
12 V
Max. output power
300 W
Physical features and ambient parameters:
Operating temperature
From -5 to +60 °C
Storage temperature
From -40 to +70 °C
Operating humidity at +25 °C
(without condensation)
Up to 95 %
Dimensions (WxHxD)
54x40x249 mm
Weight
0.65 kg
Supported devices
ME2001 router
