Data center switch MES5320-24
- Level:
- L3
- Bandwidth:
- 1.6 Tbps
- Interfaces:
- 24х25G SFP28, 2х100G QSFP28, 1xOOB
- Power supply:
- AC, 2 hot-swappable power supplies
Description
MES5320-24 switch is a high performance device with 25GBASE-R and 100GBASE-R4 interfaces that can be used as aggregation switch in carrier networks and as Top-of-Rack or End-of-Row switch for data centers.
The non-blocking architecture guarantees lossless packet for warding at wire speed with minimum and predictable delays for all types of traffic.
Front-to-Back ventilation provides effective cooling when using the device in modern data centers.
Fault tolerance of the device is ensured by redundant power supplies (1+1) and the use of replaceable fans. The redundant and hot-swappable fans and AC/DC power supplies along with advanced hardware monitoring functions provide high reliability and uninterrupted services.
The device supports EVPN/VXLAN technology to create networks with simple, high-performance and scalable data center architecture.
Specifications
- Interfaces:
- 24х25G SFP28, 2х100G QSFP28, 1xOOB
- MAC table:
- 131072
- Dynamic routing:
- RIP/OSPF/IS-IS/BGP
- ARP:
- 131005
- Bandwidth:
- 1.6 Tbps
- Power supply:
- AC/DC, 2 hot-swappable power supplies
- Cooling:
- Front-to-back
