IP-phone VP-30P

SIP accounts:
8
Display:
color
Additional features:
support for the extension console, HD Voice

Description

VP-30P is an up-to-date multifunctional IP phone designed for offices. High-resolution color LCD and high-performance hardware provide an intuitive interface and instant system response. The integrated gigabit switch enables connection of user’s PC and IP phone to the same Ethernet switch physical port.


Business Solution
VP-30P is designed for companies with high requirements for reliability, usability, and quality of voice data transmission.


High Quality of Sound
The high performance and reliability of VP-30P are provided by the hardware based on advanced chips. Usage of Echo cancellation and Silence Detector, as well assupport for all main audio codecs used in VoIP networks (G.711A, G.711U, G.722, G.726, G.729, OPUS, iLBC), ensures high quality of voice data when working in both networks with high and limited bandwidth.


Redundancy
In case of main Softswitch connection failure, VP-30P is switched automatically to a redundant SIP server with main server state control.



Usability
Convenient key location, intuitive menu, and user-friendly web interface provide usability of VP-30P in corporate telephone networks. Support for VP-EXT22 consoles extends the phone capabilities and increases the number of keys, which can be programmed at user’s convenience.

Advanced warranty and support packages
Extend basic package with additional paid services
Learn more

Specifications

Display:
4.3 inch
Сolor display
Support for the extension console
AutoProvision
AutoProvision (AuP) is a system for automatically configuring IP phones, updating them and monitoring their status
AutoProvision
Features and capabilities
For full specifications and manuals see Documents and files section below
Data sheet
Display, indicators and keys:
Display
Diagonal 4,3 inches (109 mm)
Resolution
800x480
Backlit
Yes
Interface languages
English or Russian
Two-color phone state LED indicator
Yes
Two-color programmable keys LED indicators
Yes
Functional keys with LED indications
Message
Headset
Microphone mute
Speakerphone
Functional keys without LED indications
Conference
Call hold
Call transfer
Redial
Volume adjustment
Programmable keys
10
Technical features:
CPU
2 cores (800 MHz)
DDR3
256 MB
NAND Flash
512 MB
OS Linux
Yes
Physical features:
RJ-45 10/100/1000 Mbps Ethernet ports
2
RJ-9 (4P4C) for handset connection
1
RJ-9 (4P4C) for headset connection
1
RJ-25 (6P6C) for extension console VP-EXT22 connection
1
Support for PoE+ 802.3at
Yes
Power adapter
Input 100-240 V AC
Output 12 V DC, 3 A
Operating temperature
From +0 to +40 °С
Relative humidity at +25 °С
Up to 80 %
Desktop implementation
Yes
Dimensions (WxHxD)
228x86x220 mm
Weight
1.011 kg
