Wireless access point WEP-200L

Wi-Fi 5:
802.11ac
MIMO:
4x4
Frequency range:
2.4 GHz, 5 GHz
Roaming:
802.11r/k/v
Power supply:
PoE 48 V/56 V

Description

Solution for enterprises
WEP-200L provides easy and secure access to a high-speed wireless network that combines many of the features and services required by corporate clients. WEP-200L will become a universal solution for organizing a wireless network with a large number of users and high traffic (office, government agencies, conference rooms, laboratories, hotels, etc.).


Scalability
The WEP-200L Wi-Fi access point is an up-to-date flexible solution that allows changing the network coverage area in order to increase the quantity of serviced mobile devices. Due to a high-performance hardware platform, scalability features and intuitive interface, it is possible to deploy wireless IT infrastructure easily and quickly.


Wireless connection
Due to support for IEEE 802.11n/ac standards, the WEP-200L access point provides up to 300 Mbps (2.4 GHz) and up to 1733 Mbps (5 GHz) data rates. The use of MIMO technology and embedded omnidirectional antennas makes WEP-200L a universal solution for corporate networks construction.


Security
WEP-200L uses up-to-date authentication and encryption technologies, that provide personal data protection and environment security of the corporate network. In particular, an individual dynamic key is used for each subscriber device working with WEP-200L.


Performance
To ensure stable and continuous operation of the device, the high-performance processors are used to achieve high data processing rates.


Power supply
The PoE technology makes it possible to install equipment in any place, regardless of the power supply source location. That allows reducing the number of cables used and lowering the total cost. The PoE technology makes installation easier and faster.

Advanced warranty and support packages
Extend basic package with additional paid services
Learn more

Specifications

Placement:
indoor
Wi-Fi 5:
802.11ac
Interfaces:
1 х 1G PoE/PoE+
Roaming:
802.11r/k/v
Captive Portal
Encryption:
WPA/WPA2
MIMO:
4x4
SoftWLC
A software controller to provide a comprehensive solution for the organization of centralized Wi-Fi networks. It includes a number of modules that perform various functions (WIDS, AirTune, portal and enterprise authorization, etc.)
SoftWLC
Features and capabilities
For full specifications and manuals see Documents and files section below
Data sheet
Interfaces:
10/100/1000BASE-T (RJ-45) with PoE support
1
Wi-Fi 2.4 GHz
b/g/n
Wi-Fi 5 GHz
a/n/ac
WLAN capabilities:
Standards support
IEEE 802.11 a/b/g/n/ac
Support for roaming
IEEE 802.11r/k/v
Data aggregation, including A-MPDU (Tx/Rx) and A-MSDU (Rx)
Yes
Prioritization and service package planning
WMM-based
Dynamic frequency selection (DFS)
Yes
Support for hidden SSID
Yes
Virtual access points
14
External access points detection
Yes
Spectrum analyzer
Yes
WDS
Yes
APSD
Yes
Network functions:
Automatic speed negotiation, duplex mode negotiation and MDI-MDI-X switch-over
Yes
VLAN support
Access, Trunk, General
DHCP client
Yes
GRE
Yes
Transmission of subscriber traffic outside of tunnels
Yes
ACL
Yes
NTP
Yes
Syslog
Yes
IPv6
Yes
Security:
Centralized authorization
RADIUS server (802.1X WPA/WPA2 Enterprise)
Encryption
WPA/WPA2
Captive Portal
Yes
Authorization via RADIUS server when logging into the device
Yes
Wireless interface specifications:
Frequency range
2400–2483.5 MHz
5150–5350 MHz
5470–5850 MHz
Modulations
BPSK, QPSK, 16QAM, 64QAM, 256QAM
Antennas
Built-in omnidirectional
Support for MU-MIMO 2×2
Yes
Bandwidth
20, 40 MHz fo 2.4 GHz
20, 40 and 80 MHz fo 5 GHz
Operating channels:
802.11b/g/n
1–13 (2401 –2483 MHz)
802.11a/n/ac
36–64 (5170–5330 MHz)
100–144 (5490–5730 MHz)
149–165 (5735–5835 MHz)
Data rate:
802.11a
54 Mbps
802.11b
11 Mbps
802.11g
54 Mbps
802.11n
2.4 GHz — 300 Mbps
5 GHz — 600 Mbps
802.11ac
Up to 1733 Mbps
Maximum power of the transmitter
2.4GHz: 18 dBm
5 GHz: 20 dBm
Built-in antenna gain
2.4 GHz: ~3 dBi
5 GHz: ~3 dBi
Receiver sensitivity
2.4 GHz: -92 dBm
5 GHz: -92 dBm
Configuration:
Remote management
Telnet, SSH
CLI
Yes
NETCONF
Yes
Web-interface
Yes
SNMP
Yes
