Wireless access point WEP-30L

Wi-Fi 6:
802.11ax
MU-MIMO:
2×2
Frequency range:
2.4 GHz, 5 GHz
Roaming:
802.11r/k/v
Power supply:
PoE 48 V/56 V
New

Description

Solution for enterprises
WEP-30L is a new Wi-Fi 6 generation access point that will provide maximum bandwidth and stable wireless connection for all connected devices. With high speed, low latency, energy efficiency, increased bandwidth and extended range, the new access points of 802.11ax standard support a broader set of applications that require maximum performance in demanding enterprise environments. The new access points will be able to provide many additional services compared to previous Wi-Fi standards.


WEP-30L is a universal solution for organization of wireless networks in highly crowded areas and high traffic environ-ments (offices, state institutions, conference halls, laboratories, hotels etc.).


Scalability
The WEP-30L is an up-to-date flexible solution that allows you to change the network coverage in order to increase the quantity of serviced mobile devices. Due to high-performance hardware platform, scalability features and easy-to-use interface, it is possible to set up IT infrastructure simply and fast.


Wireless connection
Due to support for IEEE 802.11ax standard the WEP-30L access point provides 574 Mbps (2.4 GHz) + 1201 Mbps (5 GHz) data rates. The use of MU-MIMO technology and built-in omnidirectional antennas makes WEP-30L a universal solution for corporate networks construction.


Security
For the corporate environment, modern WPA3 authentication and encryption technologies are supported, which provide personal data protection and environment security. The new generation access points meet the highest security and compatibility requirements for earlier versions of the 802.11 standard.


Performance
The high-performance processors are used in the devices in order to provide reliability and high data processing rates.


Power supply
The PoE technology makes installation of the equipment possible virtually everywhere, regardless of the power supply location. The use of PoE technology reduces total cost by discarding power cables and makes installation easier and faster.

Advanced warranty and support packages
Extend basic package with additional paid services
Learn more

Specifications

Placement:
indoor
Wi-Fi 6:
802.11ax
MU-MIMO:
2×2
Roaming:
802.11r/k/v
Captive Portal
Encryption:
WPA/WPA2/WPA3/OWE
Interfaces:
1 х 2.5G PoE
SoftWLC
A software controller to provide a comprehensive solution for the organization of centralized Wi-Fi networks. It includes a number of modules that perform various functions (WIDS, AirTune, portal and enterprise authorization, etc.)
SoftWLC
Features and capabilities
For full specifications and manuals see Documents and files section below
Data sheet
Interfaces:
10/100/1000/2500BASE-T (RJ-45) with PoE support
1
Wi-Fi 2.4 GHz
b/g/n/ax
Wi-Fi 5 GHz
a/n/ac/ax
WLAN capabilities:
Standards support
IEEE 802.11 a/b/g/n/ac/ax
Support for roaming
IEEE 802.11r/k/v
Data aggregation, including A-MPDU (Tx/Rx) and A-MSDU (Rx)
Yes
Prioritization and service package planning
WMM-based
Dynamic frequency selection (DFS)
Yes
Support for hidden SSID
Yes
Virtual access points
14
External access points detection
Yes
Spectrum analyzer
Yes
WDS
Yes
APSD
Yes
Network functions:
Automatic speed negotiation, duplex mode negotiation and MDI-MDI-X switch-over
Yes
VLAN support
Access, Trunk, General
DHCP client
Yes
GRE
Yes
Transmission of subscriber traffic outside of tunnels
Yes
ACL
Yes
NTP
Yes
Syslog
Yes
IPv6
Yes
LLDP
Yes
Security:
Centralized authorization
RADIUS server (802.1X WPA/WPA2/WPA3 Enterprise)
Encryption
WPA/WPA2/WPA3/OWE
Captive Portal
Yes
Authorization via RADIUS server when logging into the device
Yes
Wireless interface specifications:
Frequency range
2400–2483.5 MHz
5150–5350 MHz
5470–5850 MHz
Modulations
BPSK, QPSK, 16QAM, 64QAM, 256QAM, 1024QAM
Antennas
Built-in omnidirectional
Support for MU-MIMO 2×2
Yes
Bandwidth
20, 40 MHz for 2.4 GHz
20, 40 and 80 MHz for 5 GHz
Operating channels:
802.11b/g/n/ax
1–13 (2402–2482 MHz)
802.11a/n/ac/ax
36–64 (5170–5330 MHz)
100–144 (5490–5730 MHz)
149–165 (5735–5835 MHz)
Data rate:
802.11ax
574 Mbps
802.11ax
1201 Mbps
Maximum power of the transmitter
2.4 GHz: 20 dBm
5 GHz: 20 dBm
Built-in antenna gain
2.4 GHz: 3 dBi
5 GHz: ~3 dBi
Receiver sensitivity
2.4 GHz: up to -95 dBm
5 GHz: up to -95 dBm
Configuration:
Remote management
Telnet, SSH
CLI
Yes
NETCONF
Yes
Web-interface
Yes
SNMP
Yes
