Service gateway ESR-15
- Interfaces:
- 4x1G, 2x1G SFP
- Performance:
- FW - 1,53 Gbps, IPsec VPN - 267,5 Mbps, IPS/IDS - 39,5 Mbps
- Power supply:
- AC
Description
ESR-15 are service routers designed for connection of small and middle-sized offices in enterprise networks. The functionality of firewall and router allows ensuring security with various Internet connection options. The device supports advanced routing, WAN organization and network security functions.
The key elements of ESR service routers are data processing hardware acceleration means that ensure a high level of performance. Hardware and software processing is distributed among the units of the device. Hide
Advanced warranty and support packages
Extend basic package with additional paid services
Learn more
Specifications
- Interfaces:
- 4x1G, 2x1G SFP
- Firewall:
- 1,53 Gbps
- Power supply:
- AC
- FIB:
- 1M
- Routing:
- RIP/OSPF/IS-IS/BGP
- Tunneling:
- GRE/IPsec IKEv1,2/DMVPN
- GRE tunnels:
- 10
- IPsec VPN tunnels:
- 64
- MPLS
- QoS
- Performance:
- ACL/Firewall/IPS/IDS
- Cluster:
- active/standby
ECCM
Eltex Cloud Configuration Manager is a centralized system for network equipment management
Features and capabilities
For full specifications and manuals see Documents and files section below
Interfaces:
10/100/1000BASE-T (LAN/WAN)
4
1000BASE-X SFP (LAN/WAN)
2
Console RS-232 (RJ-45)
1
USB 2.0
2
USB 3.0
No
SD card slot
No
Performance:
Firewall/NAT/routing (1518B frames)
1,53 Gbps
126,1k pps
IPsec VPN (1456B frames)
267,5 Mbps
23k pps
IPS/IDS 10k rules
39,5 Mbps
8k pps
Maximum number
of competitive sessions
300 k
Network and service functions:
Switching service
VLAN
LAG/LACP
Bridge
Dynamic routing
BGP
OSPFv3
IS-IS
RIP
Tunneling
GRE
DMVPN
IPsec VPN
Remote access
PPTP, Open VPN, WireGuard, L2TP over Ipsec
Support for PPPoE-/PPTP- / L2TP\client
Network security functions
ACL
Zone-based Firewall
Protection against DoS/DDoS/Spoof attacks
IPS/IDS
Filtering by app
Network reliability assurance means
VRRP
Tracking
DHCP/Firewall failover
MultiWAN
Cluster according to the 1+1 scheme
Monitoring
Netflow
SNMP
Zabbix
SLA
Syslog Support
Service and quality management
DHCP
NAT
QOS
HTTP/HTTPS Proxy
Physical specifications and environmental parameters:
RAM
4 GB DDR4
Flash memory
8 GB eMMC
Maximum power consumption
18 W
Power supply
230 V AC
Operating temperature
From 0 to +40 °С
Storage temperature
From -40 to +70 °С
Operating humidity
No more than 80 %
Storage humidity
From 10 to 95 %
Dimensions
230x32x133 mm
Weight
0,325 kg
