Repeater RR-10

Mass production
Key features
  • Universal Wi-Fi repeater
  • 1 x Ethernet port
  • Dual-band Wi-Fi
  • Wi-Fi EasyMesh*

RR-10 is a universal wireless signal repeater designed to extend wireless networks coverage and amplify Wi-Fi signal strength. The solution helps to eliminate blind spots and optimize the operation of your Wi-Fi network.

Wireless connection
  RR-10 repeater provides high data rate due to the support for IEEE 802.11n/ac. The use of MIMO technology and internal antennas makes the RR-10 a universal solution for extending a home network and providing high-quality 4K multimedia transmission.

Advantages of EasyMesh* technology
  • Network intelligence: a self-organizing and self-optimizing network collects information and responds to network condi-tions for maximum performance
  • Efficient load balancing: allows for switching to a better connection and avoid interference
  • Scalability: allows adding multi-vendor Wi-Fi EasyMesh access points

* Not supported in the current firmware version 1.0.0

Documents and files

Main technical specifications
  • RAM 128 MB
  • Flash 16 MB
  • OS Linux 3.10
  • 1 x 10/100/1000 (RJ45) Ethernet port
  • WiFi IEEE 802.11b/g/n 2.4 GHz and 802.11a/n/ac 5 GHz
Wireless interface parameters
  • EasyMesh*
  • WPA/WPA2
  • WMM
  • WPS
  • Extended list of Wi-Fi interface configuration parameters
  • Wireless Multicast Forwarding
  • WiFi IEEE 802.11a/b/g/n/ac
  • Frequency range:
    • 2412-2472 MHz,
    • 5180-5320 MHz,
    • 5660-5805 MHz
  • MIMO:
    • 2.4 GHz 2х2
    • 5 GHz 2х2
Management and diagnostic
  • WEB interface
  • TR-069*

* Not supported in the current firmware version 1.0.0

Operational lifetime of the ELTEX equipment
In development
Mass production
Mass production is over
Sold out
Support is over
Regardless of the operational lifetime stage, Eltex provides a 12 months warranty on all its telecommunication equipment.
During the warranty period the manufacturer ensures technical support and free-of-charge repair at the Enterprise which is situated in Novosibirsk.
As part of the warranty service, technical support is provided on the first-in first-out principle.
The priority support packages of 8/5 and 27/7 types are subjects to additional charges.
