New

ONT NTX-1

In development

1 XGS-PON port
1 LAN Gigabit Ethernet

NTX-1 are high-performance multifunctional sub- scriber terminals designed to access modern telephony services, IPTV, OTT and high-speed Internet. In addition, NTX series subscriber terminals make it possible to provide users with a wide range of services and opportunities for working in a local network.

XGS-PON technology
XGS-PON technology is one of the most advanced and efficient solutions to "last mile" problems, which allows significant savings on cable infrastructure and provides symmetrical data transfer rate of up to 10 Gbps in the downlink direction and 10 Gbps in the uplink direction. Using solutions based on XGS-PON technology in access networks makes it possible to provide the end user with an access to a set of services based on the IP protocol.

Provided services

High-speed Internet access
Video streaming/High Definition TV/IPTV, Video on Demand (VoD), video conference
Online entertainment and educational programs

Application

Providing broadband access services to subscribers in apartment buildings, residential complexes, student campuses and cottage villages
Building corporate networks in large strategic enterprises and in business centers with high requirements to security and data transfer rates

Show all

The values given in the technical documentation are approximate as the device is under development. The actual specifications will be published after final testing and the model launch into pre-production.

Interfaces

PON:
- 1 × XGS-PON
LAN:
- 1 × 10/100/1000BASE-T (RJ-45)
- 1 × 100/1000/2.5G/5G/10GBASE-T (RJ-45)

Standards

ITU-T G.9807.1 XGS-PON

Functional specifications

Bridge operation mode
IGMP Snooping support

Security features

Rate limiting on ports
FEC coding

Physical features

Dimensions (W × H × D): 234 × 34 × 133 mm,
Desktop implementation
Power supply: 12 V, no more than 2 A
Operating temperature: from +5 to +40 °C
Relative humidity: up to 80 %

Show all

Descriptions

Data Sheet

Documentations

User manual. Firmware version 1.0.0

Downloads

Operational lifetime of the ELTEX equipment

Regardless of the operational lifetime stage, Eltex provides a 12 months warranty on all its telecommunication equipment.
During the warranty period the manufacturer ensures technical support and free-of-charge repair at the Enterprise which is situated in Novosibirsk.
As part of the warranty service, technical support is provided on the first-in first-out principle.
The priority support packages of 8/5 and 27/7 types are subjects to additional charges.
