Service gateway ESR-1511
- Interfaces:
- 4x1G, 4×1G Combo, 4x10G SFP+, 2x40G QSFP+
- Performance:
- FW - 14,9 Gbps, IPsec VPN - 4 Gbps, IPS/IDS - 1,1 Gbps
- Power supply:
- AC/DC
Description
The family of ESR routers is a universal hardware platform capable of performing a wide range of tasks related to network security, data encryption, subscriber termination, etc. The product line includes models that can be used in networks of various sizes — from small enterprise networks to carrier networks and data centers.
The key elements of ESR service routers are data processing hardware acceleration means that ensure a high level of performance. Hardware and software processing is distributed among the units of the device.
Functional purpose
- Scalable solution for different fields of application
- Flexible service configuration
- Interfacing with the equipment of leading manufacturers
- Hardware acceleration of data processing
Alternatives
You can purchase a similar device instead of the discontinued one
Service gateway ESR-3200L
- Interfaces:
- 8x10G SFP, 4x25G SFP28
- Performance:
- FW - 22 Gbps, IPsec VPN - 1,6 Gbps, IPS/IDS - 729 Mbps
- Power supply:
- AC/DC
Specifications
- Interfaces:
- 4x1G, 4×1G Combo, 4x10G SFP+, 2x40G QSFP+
- Performance:
- FW - 14,9 Gbps, IPsec VPN - 4 Gbps, IPS/IDS - 1,1 Gbps
- FIB:
- 1,7M
- Power supply:
- AC/DC
- Routing:
- RIP/OSPF/IS-IS/BGP
- Tunneling:
- GRE/IPsec IKEv1,2/DMVPN
- GRE tunnels:
- 500
- Safety:
- ACL/Firewall/IPS/IDS
ECCM
Eltex Cloud Configuration Manager is a centralized system for network equipment management
Features and capabilities
For full specifications and manuals see Documents and files section below
Interfaces:
Combo 10/100/1000BASE-T/1000BASE-X SFP (LAN/WAN)
4
10/100/1000BASE-T (LAN/WAN)
4
10GBASE-R SFP+/1000BASE-X SFP (LAN/WAN)
4
40GBASE-X QSFP+ (LAN/WAN)
2
Console RS-232 (RJ-45)
1
OOB
1
USB 2.0
1
SD card slot
1
Performance:
Firewall/NAT/routing (1518B frames)
14,9 Gbps
1228k pps
IPsec VPN (1456B frames)
2,2 Gbps
414,8k pps
IPS/IDS 10k rules
1,1 Gbps
212,6k pps
Maximum number of competitive sessions
8,5M
Network and service functions:
L2 Management
VLAN
LAG/LACP
Bridge
SPAN/RSPAN Mirroring
STP protocol family: rstp, vstp, mstp
Dynamic routing
BGP
OSPF
IS-IS
RIP
Tunneling
GRE
DMVPN
IPsec VPN
Remote access
PPTP, Open VPN, WireGuard, L2TP over Ipsec
Support for PPPoE-/PPTP- / L2TP client
Safety
ACL
Zone-based Firewall
Protection against DoS/DDoS attacks and notification on them
IPS/IDS
Filtering by app
Redundancy and clustering
VRRP
Tracking
DHCP/Firewall failover
MultiWAN
Cluster according to the 1+1 scheme
Monitoring
Netflow
SNMP
Zabbix
SLA
Syslog Support
Service and quality management
DHCP
NAT
QOS
HTTP/HTTPS Proxy
Physical parameters:
RAM
8 Gb DDR3
Flash memory
1 Gb NAND-Flash
Maximum power consumption
128 W
Power supply
100–240 V AC, 50–60 Hz
36–72 V DC
Operating temperature
From -10 to +45 °С
Storage temperature
From -40 to +70 С
Operating humidity
No more than 80 %
Storage humidity
From 10 % to 95 %
Dimensions
430x44x425 mm
Weight
7 kg
